Version du 20 septembre 2024 à 15:36
Mise en place des embouts de poteaux.
Difficulté
Moyen
Durée
20 minute(s)
- Pièces et outils
Pièces et outils
Embout de poteau x 4
Embout de poteau x 4
Vis PHT (x16) 4.8x25x23.4
Vis PHT (x16)
4.8x25x23.4
Visseuse
Une visseuse ou tournevis (électrique) est une machine-outil qui permet de visser et dévisser, assisté par un moteur (électrique), se basant sur le même principe que la perceuse, et possédant un limiteur de couple.
Embout de vissage cruciforme
Embout de vissage
cruciforme
Étape 1 - Vissez les embouts sur les poteaux
